Tough. Dependable. Quiet.

The lightest, most compact and fuel-efficient outboard in its class with a large reduction gear ratio leading to a powerful torque for quick acceleration and great top speed.

Suzuki 360 Model

Get familiar with the features

    Suzuki Lean Burn Control System

    Lean Burn control system

    Suzuki's Lean Burn Fuel Control Technology predicts fuel needs according to operating conditions, then delivers the optimum fuel/air mixture to the engine resulting in greater fuel economy.

    Suzuki Off-set drive shaft

    Offset drive shaft

    The offset drive allows us to make our outboard engines smaller by moving the outboards centre of gravity forward, improving weight distribution, power output, balance and reduces vibration.

    Self adjusting timing chain

    Self-adjusting timing chain

    Simple, effective and maintenance free timing chain that runs in an oil-bath so it never needs lubricating and equipped with a hydraulic tensioner so it remains properly adjusted at all times.

    Tilt limit system

    Tilt limit systems

    Protects the boat from damage when tilting the outboard, acting as both a tilt limit and trim sender, the step-free, continuous system allows you install the outboard on almost any boat.

Choose your shaft length

Choose from the following 3 options

DF90ATL

£9570

Summary icon Shaft Length Long (508mm)
Summary icon Control Type Mechanical
Summary icon Weight 156kg

DF90ATX

£9680

Summary icon Shaft Length Extra Long (635mm)
Summary icon Control Type Mechanical
Summary icon Weight 160kg
Recommended transom height: L: 508mm (20in) X: 635mm (25in)
Weight: L: 156.0kg X: 160.0kg
Bore x Stroke: 75 x 85mm
Propeller Selection (pitch): 13" - 25"
Starting System: Electric
Engine Type: DOHC 16 valve
No. of Cylinders: 4
Piston Displacement: 1502cc
Maximum Output: 66.2KW
Full Throttle Operating Range: 5,300 - 6,300
Steering: Remote
Oil Pan Capacity: 4.0L
Fuel Tank Capacity: 25L (optional)
Ignition System: Fully-transistorised
Alternator: 12V 27A
Trim Method: Power Trim and Tilt
Gear Ratio: 2.59:1
Gear Shift: F-N-R
Exhaust: Through Prop Hub Exhaust



DF90A technical details

What's in the box?

When you choose a Suzuki 4-Stroke outboard, we provide you with a completely flexible rigging kit to suit your boat and get you on the water. With the DF90A we include the following:

- Kill cord

- White trim gauge*

- Tacho and monitor gauge*

- Choice of control box

- Choice of aluminium propeller

- Wiring harness

- Suzuki Keyless Start System

- 5 year leisure warranty / 2 year commercial warranty

- Free Datatag security marking with all Suzuki Marine insurance policies

* Upgrade to Suzuki Multi-Function Gauge available, please ask your local Suzuki Authorised Dealer for more information.

Why choose Suzuki Innovation

Suzuki have won a total of eight National Marine Manufacturers' Association (NMMA) Innovation Awards - more than any other outboard manufacturer.

Why choose Suzuki Long-term Value

As every engine in our range is designed specifically for the rigours of marine use our 4-Stroke outboards provide quiet, fuel-efficient and reliable technology whilst delivering market-leading power and performance.

Why choose Suzuki 50 years experience

50 years of leading the way in innovation – from bringing the down thrust propeller system to market in 1965, to introducing the world’s first 300HP V6 4-Stroke outboard in 2006.

Why choose Suzuki Peace of mind

As well as offering a five-year leisure or two-year commercial warranty on all of our 4-stroke outboards, we also have a nationwide network of Suzuki Authorised Dealers who are always on hand to provide support wherever you are, whenever you need it.
